BAY TERMINAL
the usual safety with the adaptability of new technologies
GraL, or Graphical Loading, embodies innovation in continuity with the past.
GraL is the bay terminal that constitutes the single interface between the driver, bay instrumentation, and Terminal Automation System (TAS). The driver will be able to control all bay loading operations through its large colour display and capacitive functional numeric keypad.
Loading directives from the TAS, commands, field I/O control, diagnostics, and finalisation of end-load data are managed by GraL, eliminating the need to individually consult the different flow computers of loading arms.
Flow computers, GraL, and TAS communicate on the same field LAN thus simplifying operations and connections engineering.
CONSISTENTLY RELIABLE DESIGN AND TECHNOLOGY
the best terminal for oil product loading control
01 . High-brightness colour 15” LCD.
02 . Reliable interface to guide the operator quickly and easily through tanker loading procedures.
03 . Configuration, diagnostic and test functions are available to authorised operators through the same graphic interface. These functions make it possible to easily maintain the terminal and loading bay.
04 . Simultaneous load control for up to 6 loading arms.
05 . Additive, mixing, denaturing, and blending control.
06 . Management of earthing and/or anti-overflow devices, tanker presence, and emergency signals.
07 . I/O management for bay logics.
08 . Proximity badge reader and capacitive keyboard (devices without mechanical parts).
09 . Interface to flow computers and third-party supplier instrumentation.
10 . IP65 enclosure.
11 . Exd IIB ATEX protection mode.
FUNCTIONAL FEATURES
a New Terminal Family For Greater Flexibility
MODERN AND EASILY EXPANDABLE ARCHITECTURE
GraL, in its first version, extends all the functionalities of the IBIS automation terminals with a modern, easily expandable, and adaptable technological architecture.
HARDWARE ARCHITECTURE FOR GREAT EXPANDABILITY
Thanks to its hardware architecture, GraL guarantees great expandability: additive processing, denaturation, mixing, pump control, etc.
SIMPLE AND FAST GRAPHICAL INTERFACE
GraL allows drivers to control all loading operations in the bay through its colour display and keyboard, eliminating the need to consult different flow computers. The display consistently shows data on required quantities, dispensed quantities, individual presets, and error messages/operator guidance. The graphic interface simplifies and accelerates loading, calibration, and diagnostics.
INTEGRAL PART OF NUOVO PETROL SYSTEM
Although it is capable of operating autonomously, GraL is an integral part of the LOGINET (NUOVO PETROL) Load and Shipping Automation System and it is also designed to connect with other suppliers’ automation systems.
other Technical Features
CPU
Integrated industrial PC based on Windows CE .Net 6.0, 16 integrated digital I/O (expandable) 1 Ethernet port 6 RS-232 serial lines 1 RS-422/485 serial line
KEYPAD
Capacitive with digital control 22 numeric-functional keys
DISPLAY
Ultra-high brightness colour 15” LCD
BADGE READER
Proximity-based with a passive radio card. Physical features of the card according to ISO7816 standard (credit card size) and MIFARE
POWER SUPPLY
Voltage: 220Vac ±5%, 50 or 110Hz Power consumption: 250W max
DIMENSIONS
x670 x 240 mm (HxWxD) Weight: 40 kg
OPERATING CONDITIONS
Operating temperature: >-15°C to <+50°C Protection rating: IP65
CERTIFICATIONS
In compliance with CEI EN 50014/50018 standards suitable for explosive environments classified as C1Z1, in compliance with CEI standards Eex d IIB (ATEX) protection mode
