HARDWARE FOR MONITORING AND REMOTE EVENT ALERT
remote control of devices, environments and events
E.R.Mes, or Electronic Responsive Messenger, is a hardware designed for monitoring and remote controlling of instrumentation and environments. E.R.Mes can send detailed notifications and text messages in case of events or alarms.
REMOTE NOTIFICATIONS AND ALERTS
monitor environments and events with instant notifications through smartphone and mobile devices
01 . GSM module for automatic text message (SMS) sending.
02 . 4 configurable inputs and 4 outputs.
03 . LAN network interface.
04 . Rechargeable backup battery.
FUNCTIONAL FEATURES
complete integration with all systems and events you want to supervise
CONFIGURABLE IN DRY MODE
E.R.Mes I is capable of controlling up to 4 configurable dry or wet input contacts, allowing the connection of various sensor models (e.g., smoke alarms, level sensors, temperature sensors, etc.).
MANAGEMENT OF NOTIFICATION AND ALARM RECIPIENTS
It is possible to receive alarm notifications directly on your mobile phone via SMS and/or activate one or more signalling devices and/or control equipment.
SIMPLE SYSTEM MANAGEMENT
Through the network interface, it is possible to interact with E.R.Mes from a remote system to control the activation/deactivation of outputs and the sending of SMS.
BACKUP BATTERY
Thanks to its rechargeable backup battery, E.R.Mes is capable of monitoring connected devices, even during a power outage.
other Technical Features
POWER SUPPLY
220 Vac with EMC protection filter
DIMENSIONS
165 X 240 X 60 mm
OPERATING CONDITIONS
-20°C to +55°C, IP40
CERTIFICATIONS
CE, Compliant with standards: EN 61000 – 2 (2005), en 61000-6-4 (2007), UL94-V0 ABS
COMMUNICATION INTERFACES
LAN network interface, GSM modem
INPUTS
4 opto-isolated digital inputs with deep switch for selecting dry/powered contact 0÷12/24 V
OUTPUTS
4 digital outputs with G6DN-1° relays (Max current: 5A at 250 Vac or 30 Vdc) in compliance with EN61010-1 and EN61010-2-201 standards for isolation (CTI 600 V min., nominal isolation 300 V)
LIGHT INDICATORS
Light signals for correct functioning and anomalies
